DVS to EVOAQ Upgrade Kit
DVS to EVOAQ Upgrade Kit - Image 2
DVS to EVOAQ Upgrade Kit - Image 3
DVS to EVOAQ Upgrade Kit - Image 4
DVS to EVOAQ Upgrade Kit - Image 5
DVS to EVOAQ Upgrade Kit - Image 6
DVS to EVOAQ Upgrade Kit - Image 7

DVS to EVOAQ Upgrade Kit

Price range: $1,426.00 through $1,656.00

- +
SKU: R-AQ-DVS-KIT Categories: , Tags: , , , , , , , , , Brand:

EVOAQ Fully compatible DVS Replacement/Upgrade Kit

Having issues with your DVS system and want to try something different? This kit is suitable to replace the fan, filter, and controller of your HRV system, while keeping your existing ducting and outlet diffusers in place.

We have 2 different kits available based on fan size, 150mm and 200mm. The fan size is determined by the number of outlets/rooms your system has:

  • Up to 5 rooms/outlets: 150mm fan
  • 6 or more rooms/outlets: 200mm fan

Please select the number of rooms to get the correct kit for your home.





Fan Size150mmFan with 150mm diameter duct connection, 200mm Fan with 200mm diameter duct connection
Duct Size

150mm, 200mm

External Grille

None

Fan Motor TypeEC Motor 230VAC Electronically Commutated (EC) fan motor, with 10-100% variable speed controllability
Fan Type

Inline Fan

Filter typeF7 FilterPM2.5 (F7 equivalent) filter, HEPA Filter HEPA Filter Screen
G4 ComplianceCompliant with G4 Building code This system is compliant with G4 Building Code ventilation requirements (as per NZS 4303:1990). This means ventilation systems are capable of delivering at least 7.5L/s per person of fresh air to living spaces; bathroom/laundry fans can provide at least 10L/s continuous and/or 25L/s intermittent extraction; and kitchen fans can provide at least 12L/s continuous and/or 50L/s intermittent extraction.
Internal Grille Size150mm cone diffuser 150mm Duct connection size. Face size is 200mm diameter.
Sensor Type

Humidity, Temperature

Speed ControlsAir Quality MonitoringAir Quality Monitoring is EVOAQ's proprietary sensor software controls, with humidity and temperature sensor control technology designed for NZ homes, Wall Controller Systems with a wall controller allow for user adjustment of the system operation via wall-mounted thermostat control.
